List of APIs

GET report/filter/operators

Returns the list filter operators grouped by data type.

Request

No payload

Response

An array of ReportFilterOperatorGroup objects

Samples

GET/api/report/filter/operatorsHTTP/1.1

Sample response:

[{"key":"...","filterOperators":[{"key":"...","name":"...","operatorGroupId":"95051abc-70eb-4908-8d13-04032aab3c66","id":"1476ed4b-17ac-4e39-be1b-0a25f705ebea","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"}],"name":"...","id":"95051abc-70eb-4908-8d13-05032aab3c66","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320056Z"},{"key":"boolean","filterOperators":[{"key":"...","name":"...","operatorGroupId":"7b127c0c-4996-4df8-aa72-09cf07569f5e","id":"a52e09eb-8867-45e5-88bc-12ba9434f16f","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"blank","name":"Blank","operatorGroupId":"7b127c0c-4996-4df8-aa72-09cf07569f5e","id":"c77e5ab6-890d-4bf6-8773-13cc9c3bf67e","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notblank","name":"Not Blank","operatorGroupId":"7b127c0c-4996-4df8-aa72-09cf07569f5e","id":"a8339c19-7b65-4ee7-8ef4-13e340fba2e9","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"true","name":"True","operatorGroupId":"7b127c0c-4996-4df8-aa72-09cf07569f5e","id":"31d3e116-bde2-40d1-b259-2d750348299c","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"false","name":"False","operatorGroupId":"7b127c0c-4996-4df8-aa72-09cf07569f5e","id":"086dc2fc-23e3-4b54-bc46-2e5f572d2d3f","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"}],"name":"Boolean","id":"7b127c0c-4996-4df8-aa72-09cf07569f5e","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320056Z"},{"key":"comparison","filterOperators":[{"key":"...","name":"...","operatorGroupId":"08b322e2-ac79-406d-8367-046437b4fcd9","id":"f8a69ec3-bc01-40fd-8dc1-0b7a259ee83e","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"blank","name":"Blank","operatorGroupId":"08b322e2-ac79-406d-8367-046437b4fcd9","id":"6bac46ba-768f-4764-9109-0bc2736bcbfd","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notblank","name":"Not Blank","operatorGroupId":"08b322e2-ac79-406d-8367-046437b4fcd9","id":"ce0fda8a-4515-409c-9d00-0bf56c2b4c4d","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"islessthan","name":"Is Less Than","operatorGroupId":"08b322e2-ac79-406d-8367-046437b4fcd9","id":"b78305b3-70f4-4724-a02c-1617a0ef95d3","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"isgreaterthan","name":"Is Greater Than","operatorGroupId":"08b322e2-ac79-406d-8367-046437b4fcd9","id":"53d73892-3a12-45cd-8b69-163ff6c41989","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"between","name":"Between","operatorGroupId":"08b322e2-ac79-406d-8367-046437b4fcd9","id":"94c4fb2e-c5d3-4160-a2f7-173418ca4e66","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notlessthan","name":"Not Less Than","operatorGroupId":"08b322e2-ac79-406d-8367-046437b4fcd9","id":"9fe2afd6-8fb6-4a34-b2e2-1822323af768","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notgreaterthan","name":"Not Greater Than","operatorGroupId":"08b322e2-ac79-406d-8367-046437b4fcd9","id":"0526507d-901b-4d41-8c4b-1831f90b180c","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notbetween","name":"Not Between","operatorGroupId":"08b322e2-ac79-406d-8367-046437b4fcd9","id":"6ea8396b-49e3-4ed2-b9b6-18c1a737cffc","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"}],"name":"Comparison","id":"08b322e2-ac79-406d-8367-056437b4fcd9","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320056Z"},{"key":"date&time","filterOperators":[{"key":"...","name":"...","operatorGroupId":"01076b28-8e77-4a54-95d8-060d142a77e6","id":"27a17b83-4b6a-4700-91a7-10558ef6ab23","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"blank","name":"Blank","operatorGroupId":"01076b28-8e77-4a54-95d8-060d142a77e6","id":"98e2ec4a-f34f-4bf1-b2b2-108fbec8fa5b","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notblank","name":"Not Blank","operatorGroupId":"01076b28-8e77-4a54-95d8-060d142a77e6","id":"63f26c6a-f763-4947-8517-10fd79de5e2a","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"between(calendar)","name":"Between (Calendar)","operatorGroupId":"01076b28-8e77-4a54-95d8-060d142a77e6","id":"78376aea-4d3c-4e8d-ab97-25c6c249be62","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notbetween(calendar)","name":"Not Between (Calendar)","operatorGroupId":"01076b28-8e77-4a54-95d8-060d142a77e6","id":"5522a5d7-0456-432b-b1fb-02a4283baa3d","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"equals(calendar)","name":"Equals (Calendar)","operatorGroupId":"01076b28-8e77-4a54-95d8-060d142a77e6","id":"cb64b1fd-6dec-4b18-b348-02b5b984e6c6","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notequal(calendar)","name":"Not Equal (Calendar)","operatorGroupId":"01076b28-8e77-4a54-95d8-060d142a77e6","id":"4d68d4a2-05ac-4f24-8496-02c1cfe75460","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"intimeperiod","name":"In Time Period","operatorGroupId":"01076b28-8e77-4a54-95d8-060d142a77e6","id":"f6b2f9d3-464d-4399-bfd2-265009d3fcf1","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"lessthandaysold","name":"Less Than Days Old","operatorGroupId":"01076b28-8e77-4a54-95d8-060d142a77e6","id":"05f7ea30-001d-4779-ad3b-2732ed97d61e","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"greaterthandaysold","name":"Greater Than Days Old","operatorGroupId":"01076b28-8e77-4a54-95d8-060d142a77e6","id":"1c6b9fbd-6377-4c8b-9acc-286ff0e853c5","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"equalsdaysold","name":"Equals Days Old","operatorGroupId":"01076b28-8e77-4a54-95d8-060d142a77e6","id":"a8d45242-f5f0-4839-ae98-287ddc178c96","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"}],"name":"Date & Time","id":"01076b28-8e77-4a54-95d8-060d142a77e6","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320056Z"},{"key":"equivalence","filterOperators":[{"key":"...","name":"...","operatorGroupId":"e023c1f4-42b3-469b-a8d9-04684feeb4ed","id":"0f043b65-e45d-4c22-9634-0da9e96493bc","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"blank","name":"Blank","operatorGroupId":"e023c1f4-42b3-469b-a8d9-04684feeb4ed","id":"d7096bd5-09e5-433d-924e-0e038bdc81fb","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notblank","name":"Not Blank","operatorGroupId":"e023c1f4-42b3-469b-a8d9-04684feeb4ed","id":"85252e31-7588-438f-85ff-0e0e9c16df8d","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"equals(manualentry)","name":"Equals (Manual Entry)","operatorGroupId":"e023c1f4-42b3-469b-a8d9-04684feeb4ed","id":"737307d1-1e5f-407f-889f-1b3c9a66dd6f","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"equals(selection)","name":"Equals (Selection)","operatorGroupId":"e023c1f4-42b3-469b-a8d9-04684feeb4ed","id":"042a04a3-dfe1-4ef9-bd27-1b657886f02e","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"equals(popup)","name":"Equals (Popup)","operatorGroupId":"e023c1f4-42b3-469b-a8d9-04684feeb4ed","id":"bb2f8e2d-753e-4fc9-9646-1b977a043b9a","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"equals(tree)","name":"Equals (Tree)","operatorGroupId":"e023c1f4-42b3-469b-a8d9-04684feeb4ed","id":"003c0e13-cc3c-412f-8fee-1cf21aa51e31","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"equals(checkbox)","name":"Equals (Checkbox)","operatorGroupId":"e023c1f4-42b3-469b-a8d9-04684feeb4ed","id":"5ce630bc-6615-42c4-b11e-1d09c651eaae","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notequal(manualentry)","name":"Not Equal (Manual Entry)","operatorGroupId":"e023c1f4-42b3-469b-a8d9-04684feeb4ed","id":"78ba4663-e8a4-407f-bab2-1dc014a4df56","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notequal(selection)","name":"Not Equal (Selection)","operatorGroupId":"e023c1f4-42b3-469b-a8d9-04684feeb4ed","id":"75fcf433-81f2-4767-94b7-1e4257b826c4","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notequal(popup)","name":"Not Equal (Popup)","operatorGroupId":"e023c1f4-42b3-469b-a8d9-04684feeb4ed","id":"5cdacf39-8eed-4ed3-8684-1e4461e85e1b","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notequal(checkbox)","name":"Not Equal (Checkbox)","operatorGroupId":"e023c1f4-42b3-469b-a8d9-04684feeb4ed","id":"de9ab97b-4e57-4c8c-8415-1e5030415b50","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notequal(tree)","name":"Not Equal (Tree)","operatorGroupId":"e023c1f4-42b3-469b-a8d9-04684feeb4ed","id":"6bc89182-aa4c-4fa5-b151-208af7e8cd59","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"}],"name":"Equivalence","id":"e023c1f4-42b3-469b-a8d9-05684feeb4ed","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320056Z"},{"key":"fieldcomparison","filterOperators":[{"key":"...","name":"...","operatorGroupId":"6938e8a8-c810-4044-be0b-05709faa4734","id":"444b32e1-5ba5-4829-a8dc-0e3a0e6a69f3","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"blank","name":"Blank","operatorGroupId":"6938e8a8-c810-4044-be0b-05709faa4734","id":"83849954-987f-4213-b5b3-0febf0251d5c","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notblank","name":"Not Blank","operatorGroupId":"6938e8a8-c810-4044-be0b-05709faa4734","id":"38a333fb-39cf-424c-bbaf-1043600ca055","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"islessthan(field)","name":"Is Less Than (Field)","operatorGroupId":"6938e8a8-c810-4044-be0b-05709faa4734","id":"c506759f-c000-46c3-a35a-21b7d5bbd447","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"isgreaterthan(field)","name":"Is Greater Than (Field)","operatorGroupId":"6938e8a8-c810-4044-be0b-05709faa4734","id":"de669d47-d040-494c-91d9-21df45009964","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"equals(field)","name":"Equals (Field)","operatorGroupId":"6938e8a8-c810-4044-be0b-05709faa4734","id":"ecd32d5d-32ce-493e-8f9f-225647357325","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notequal(field)","name":"Not Equal (Field)","operatorGroupId":"6938e8a8-c810-4044-be0b-05709faa4734","id":"1e9fbb61-8a77-48a6-b95e-2357646360a5","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"}],"name":"Field Comparison","id":"6938e8a8-c810-4054-be0b-05709faa4734","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320056Z"},{"key":"string","filterOperators":[{"key":"...","name":"...","operatorGroupId":"c1b10232-6c6f-4bd5-91a1-09317a2b2e67","id":"97040a0e-7c33-4088-90ac-1146428428df","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"blank","name":"Blank","operatorGroupId":"c1b10232-6c6f-4bd5-91a1-09317a2b2e67","id":"c16bc286-3238-4a36-85e5-123eb989bee8","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notblank","name":"Not Blank","operatorGroupId":"c1b10232-6c6f-4bd5-91a1-09317a2b2e67","id":"966019de-d541-4ee4-9235-125732abb75a","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"like","name":"Like","operatorGroupId":"c1b10232-6c6f-4bd5-91a1-09317a2b2e67","id":"3396325a-4233-4180-8513-2bb991627800","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"beginswith","name":"Begins With","operatorGroupId":"c1b10232-6c6f-4bd5-91a1-09317a2b2e67","id":"0ac3a76f-cf80-4cd7-8cfd-2c74fadb330a","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"endswith","name":"Ends With","operatorGroupId":"c1b10232-6c6f-4bd5-91a1-09317a2b2e67","id":"09b9b1ba-21c5-4f05-808c-2cae6cca56d9","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"},{"key":"notlike","name":"Not Like","operatorGroupId":"c1b10232-6c6f-4bd5-91a1-09317a2b2e67","id":"30dd377c-5217-4665-8896-2d61efc73cfc","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320046Z"}],"name":"String","id":"c1b10232-6c6f-4bd5-91a1-09317a2b2e67","state":0,"modified":null,"dateTimeNow":"2016-06-13T07:49:32.7320056Z"}]

POST report/loadFilterDataSource

Returns a list of available report filter fields.

Request

Payload: a ReportSavingParameter object, with either:

• reportKey field populated - for an existing/draft report.
• reportKey empty and reportDataSource.querySourceId populated - for a new report.

Response

An array of ReportFilterField objects

Samples

POST/api/report/loadFilterDataSourceHTTP/1.1

Request payload for a draft report:

{"reportKey":{"key":"b95d2611-10c5-4808-aa68-9db2ccc719ff"}}

Sample response:

[{"connectionName":"MSSQL","querySourceCategoryName":"dbo","sourceFieldName":"CategoryID","sourceFieldVisible":true,"sourceFieldFilterable":true,"sourceDataObjectName":"Categories","sourceDataObjectFullName":null,"dataType":"Numeric","isParameter":false,"isCalculated":false,"calculatedTree":null,"compareFieldCalculatedTree":null,"compareValueCalculatedTree":null,"compareField":null,"selected":false,"dataFormat":null,"reportId":null,"useMappedFieldAlias":false,"uniqueId":null,"comparisionValue":null,"inTimePeriodType":null,"valueInTimePeriod":null,"hasModifiedCalculatedTree":false,"isHiddenFilter":false,"isInheritableFilter":false,"operatorName":null,"filterId":"00000000-0000-0000-0000-000000000000","reportFieldAlias":null,"reportPartTitle":null,"querySourceFieldId":"1c21c9b2-cc58-4181-89b5-76740bf04c64","querySourceType":"Table","querySourceId":"8ea14631-ce4f-4546-a6e9-04094c69d4af","relationshipId":null,"alias":null,"position":0,"visible":true,"required":false,"cascading":true,"operatorId":null,"operatorSetting":null,"value":null,"dataFormatId":null,"sortType":"Unsorted","fontFamily":null,"fontSize":0,"textColor":null,"backgroundColor":null,"fontBold":false,"fontItalic":false,"fontUnderline":false,"querySourceUniqueName":null,"querySourceFieldName":null,"comparisonFieldUniqueName":null,"isNegative":false,"id":"00000000-0000-0000-0000-000000000000","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"connectionName":"MSSQL","querySourceCategoryName":"dbo","sourceFieldName":"CategoryName","sourceFieldVisible":true,"sourceFieldFilterable":true,"sourceDataObjectName":"Categories","sourceDataObjectFullName":null,"dataType":"Text","isParameter":false,"isCalculated":false,"calculatedTree":null,"compareFieldCalculatedTree":null,"compareValueCalculatedTree":null,"compareField":null,"selected":false,"dataFormat":null,"reportId":null,"useMappedFieldAlias":false,"uniqueId":null,"comparisionValue":null,"inTimePeriodType":null,"valueInTimePeriod":null,"hasModifiedCalculatedTree":false,"isHiddenFilter":false,"isInheritableFilter":false,"operatorName":null,"filterId":"00000000-0000-0000-0000-000000000000","reportFieldAlias":null,"reportPartTitle":null,"querySourceFieldId":"8a628514-1024-4051-92a8-33752b79d58b","querySourceType":"Table","querySourceId":"8ea14631-ce4f-4546-a6e9-04094c69d4af","relationshipId":null,"alias":null,"position":0,"visible":true,"required":false,"cascading":true,"operatorId":null,"operatorSetting":null,"value":null,"dataFormatId":null,"sortType":"Unsorted","fontFamily":null,"fontSize":0,"textColor":null,"backgroundColor":null,"fontBold":false,"fontItalic":false,"fontUnderline":false,"querySourceUniqueName":null,"querySourceFieldName":null,"comparisonFieldUniqueName":null,"isNegative":false,"id":"00000000-0000-0000-0000-000000000000","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null}]

Request payload for a new report:

{"reportKey":{"key":null,"modified":null,"tenantId":null},"report":{"reportDataSource":[{"querySourceId":"8ea14631-ce4f-4546-a6e9-04094c69d4af","querySourceName":"Categories"},{"querySourceId":"9338a5fd-336b-4fdf-a9c5-dfe9e66b5be2","querySourceName":"Products"}]}}

Sample response is similar to above.

POST report/validateFilterSyntax

Validates a filter syntax.

Request

Payload: a FilterSyntax object

Response

An OperationResult object, with the success field true if the syntax is valid

Samples

POST/api/report/validateFilterSyntaxHTTP/1.1

Request payload:

{"availableFilter":[1,2,3,4],"syntax":"(1 OR 2) AND (3 OR 4)"}

Sample response:

{"success":true,"messages":null}

POST report/loadFilter

Returns the report’s filter fields, with data source and data source field names replaced by correct alias defined in Data Model.

Request

Payload: a ReportFilterParameter object

Response

A ReportFilterSetting object

Samples

POST/api/report/loadFilterHTTP/1.1

Request payload:

{"reportKey":{"key":"d5771750-9cec-4ef8-b3c0-ff62d12a4e1f"}}

Response:

{"filterFields":[{"connectionName":"Northwind","querySourceCategoryName":"dbo","sourceFieldName":"","sourceFieldVisible":true,"sourceFieldFilterable":true,"sourceDataObjectName":"Orders","sourceDataObjectFullName":"Northwind.dbo.Orders","dataType":"Money","isParameter":false,"calculatedTree":null,"selected":false,"filterId":"e4bf0bd8-6fd8-47f0-8b50-580455c371da","reportFieldAlias":null,"querySourceFieldId":"8c3a5156-b571-4232-9577-3d4ea247c022","querySourceType":"Table","querySourceId":"04067f51-5551-4f22-a760-ad4f804de79c","relationshipId":"00000000-0000-0000-0000-000000000000","alias":"Freight","position":1,"visible":false,"required":false,"cascading":true,"operatorId":"53d73892-3a12-45cd-8b69-163ff6c41989","operatorSetting":null,"value":"100","dataFormatId":"00000000-0000-0000-0000-000000000000","sortType":"Unsorted","fontFamily":null,"fontSize":0,"textColor":null,"backgroundColor":null,"fontBold":false,"fontItalic":false,"fontUnderline":false,"id":"8e5e49e5-0a5a-49c5-94f7-7126d9b913dc","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null}],"logic":"","visible":false,"reportId":"d5771750-9cec-4ef8-b3c0-ff62d12a4e1f","id":"e4bf0bd8-6fd8-47f0-8b50-580555c371da","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null}

POST report/filter/loadFields

Request

Payload: a ReportFilterParameter object.

Response

An array of ReportFilterField object

Samples

POST/api/report/filter/loadFieldsHTTP/1.1

Sample Request Payload:

{"reportKey":{"key":"5447a5c1-a0c8-4bf6-bd68-f09234ba5e84"},"filterId":"021c76a2-b108-4dd3-962c-4d5d2d1b22fe","fieldId":"4f43a428-6e23-42c9-bb51-ab19f7966943"}

Sample Response:

{"connectionName":null,"querySourceCategoryName":null,"sourceFieldName":"ShipperID","sourceFieldVisible":false,"sourceFieldFilterable":false,"sourceDataObjectName":"Shippers","sourceDataObjectFullName":"SQL-Northwind.dbo.Shippers","dataType":null,"isParameter":false,"isCalculated":false,"calculatedTree":null,"compareFieldCalculatedTree":null,"compareValueCalculatedTree":null,"compareField":null,"selected":false,"dataFormat":null,"reportId":null,"useMappedFieldAlias":false,"uniqueId":null,"comparisionValue":null,"inTimePeriodType":null,"valueInTimePeriod":null,"hasModifiedCalculatedTree":false,"isHiddenFilter":false,"isInheritableFilter":false,"operatorName":null,"type":0,"isRunningField":false,"isDrillDown":false,"filterId":"021c76a2-b108-4dd3-962c-4d5d2d1b22fe","reportFieldAlias":null,"reportPartTitle":null,"querySourceFieldId":"d5a8a521-6832-4973-8b2c-3360dc52814c","querySourceType":"Table","querySourceId":null,"relationshipId":null,"alias":"ShipperID","position":1,"visible":true,"required":false,"cascading":true,"operatorId":"737307d1-1e5f-407f-889f-1b3c9a66dd6f","operatorSetting":null,"value":"","dataFormatId":null,"sortType":"ASC","fontFamily":"Roboto","fontSize":14,"textColor":"#000","backgroundColor":"#fff","fontBold":false,"fontItalic":false,"fontUnderline":false,"querySourceUniqueName":"[con;#0].[cat;#0].[Shippers]","querySourceFieldName":"ShipperID","comparisonFieldUniqueName":"","isNegative":false,"id":"4f43a428-6e23-42c9-bb51-ab19f7966943","state":0,"deleted":false,"inserted":true,"version":1,"created":"2017-09-28T07:49:39.2630000+07:00","createdBy":"System5 Admin5","modified":"2017-09-28T07:49:39.2630000+07:00","modifiedBy":"System5 Admin5"}

GET report/filter/timePeriods

Returns pre-defined time periods (last week, next year, etc).

This API also returns custom time periods if available (see IAdHocExtension’s CustomTimePeriod).

Request

No payload

Response

An array of TimePeriod object

Samples

GET/api/report/filter/timePeriodsHTTP/1.1

Sample response:

[{"name":"In the Future","type":"Long-term Period","value":"","isCustomFilter":false,"customId":"b8ef8ad0-7a90-4f70-b3f3-52cbaf518335","id":"b8ef8ad0-7a90-4f70-b3f3-52cbaf518335","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"In the Past","type":"Long-term Period","value":"","isCustomFilter":false,"customId":"dae256be-21d4-45c1-8d34-52cf05ba7cf5","id":"dae256be-21d4-45c1-8d34-52cf05ba7cf5","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Current Fiscal Year","type":"Fiscal Year","value":"0","isCustomFilter":false,"customId":"1559a72d-22a1-4c8e-b3b4-53414e5b7ff5","id":"1559a72d-22a1-4c8e-b3b4-53414e5b7ff5","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Previous Fiscal Year","type":"Fiscal Year","value":"-1","isCustomFilter":false,"customId":"4c35be45-4b5e-4fc2-931f-53acf34bf7dd","id":"4c35be45-4b5e-4fc2-931f-53acf34bf7dd","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Next Fiscal Year","type":"Fiscal Year","value":"1","isCustomFilter":false,"customId":"7aad066f-fbcc-4494-9343-54a803244fa0","id":"7aad066f-fbcc-4494-9343-54a803244fa0","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Current and Previous Fiscal Year","type":"Fiscal Year","value":"0&-1","isCustomFilter":false,"customId":"6bc051a5-85a1-401e-b5bb-55480ec6485e","id":"6bc051a5-85a1-401e-b5bb-55480ec6485e","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Current and Next Fiscal Year","type":"Fiscal Year","value":"0&1","isCustomFilter":false,"customId":"f1e19c1e-0970-4b3a-b1fa-5561efc783e5","id":"f1e19c1e-0970-4b3a-b1fa-5561efc783e5","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Current Fiscal Quarter","type":"Fiscal Quarter","value":"0","isCustomFilter":false,"customId":"52cc45ab-3d7c-4814-a237-55d43b41b385","id":"52cc45ab-3d7c-4814-a237-55d43b41b385","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Current and Next Fiscal Quarter","type":"Fiscal Quarter","value":"0&1","isCustomFilter":false,"customId":"f64ee3b3-0f5d-4ac4-a0db-561cfed6d00c","id":"f64ee3b3-0f5d-4ac4-a0db-561cfed6d00c","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Current and Previous Fiscal Quarter","type":"Fiscal Quarter","value":"0&-1","isCustomFilter":false,"customId":"4a689982-d21e-41a8-9ee6-565b6e23985a","id":"4a689982-d21e-41a8-9ee6-565b6e23985a","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Next Fiscal Quarter","type":"Fiscal Quarter","value":"1","isCustomFilter":false,"customId":"eaae70a0-ce64-45df-9a43-5737bb110bd4","id":"eaae70a0-ce64-45df-9a43-5737bb110bd4","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Previous Fiscal Quarter","type":"Fiscal Quarter","value":"-1","isCustomFilter":false,"customId":"35e57b59-a63b-47bb-80d8-574b9e7fd4b0","id":"35e57b59-a63b-47bb-80d8-574b9e7fd4b0","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Current & Next 3 Fiscal Quarter","type":"Fiscal Quarter","value":"0&1&2&3","isCustomFilter":false,"customId":"d41cf2a0-41ec-4e62-a9bd-57916b9ea6bc","id":"d41cf2a0-41ec-4e62-a9bd-57916b9ea6bc","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Current Year","type":"Calendar Year","value":"0","isCustomFilter":false,"customId":"fa1b763b-206f-42f7-a99b-597d7c97582e","id":"fa1b763b-206f-42f7-a99b-597d7c97582e","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Previous Year","type":"Calendar Year","value":"-1","isCustomFilter":false,"customId":"eedd820b-3a54-47a1-8c6e-59fc077464dd","id":"eedd820b-3a54-47a1-8c6e-59fc077464dd","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Current Calendar Quarter","type":"Calendar Quarter","value":"0","isCustomFilter":false,"customId":"bfd892b0-f905-48e1-9766-5a894da73115","id":"bfd892b0-f905-48e1-9766-5a894da73115","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Current & Next Calendar Quarter","type":"Calendar Quarter","value":"0&1","isCustomFilter":false,"customId":"ebe01191-9c66-4324-9fc2-5aa7497ba130","id":"ebe01191-9c66-4324-9fc2-5aa7497ba130","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Current & Previous Calendar Quarter","type":"Calendar Quarter","value":"0&-1","isCustomFilter":false,"customId":"12a7ff3a-cbe0-437b-b0f0-5bb731c69a40","id":"12a7ff3a-cbe0-437b-b0f0-5bb731c69a40","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Next Calendar Quarter","type":"Calendar Quarter","value":"1","isCustomFilter":false,"customId":"ad5dcad5-cf2f-4207-82f1-5bcdde289ed1","id":"ad5dcad5-cf2f-4207-82f1-5bcdde289ed1","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Previous Calendar Quarter","type":"Calendar Quarter","value":"-1","isCustomFilter":false,"customId":"5497b872-bf2f-4e2a-9e69-5c6b4a5917ce","id":"5497b872-bf2f-4e2a-9e69-5c6b4a5917ce","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Current & Next 3 Calendar Quarter","type":"Calendar Quarter","value":"0&1&2&3","isCustomFilter":false,"customId":"66716758-155f-46a2-a03d-5ca2e2d31894","id":"66716758-155f-46a2-a03d-5ca2e2d31894","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Last Month","type":"Calendar Month","value":"-1","isCustomFilter":false,"customId":"007f892b-1de2-4bcb-b0c4-5d0a91007a54","id":"007f892b-1de2-4bcb-b0c4-5d0a91007a54","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"This Month","type":"Calendar Month","value":"0","isCustomFilter":false,"customId":"3a94dc2b-e390-4226-b28b-5d20cdd07d17","id":"3a94dc2b-e390-4226-b28b-5d20cdd07d17","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Next Month","type":"Calendar Month","value":"1","isCustomFilter":false,"customId":"39e5d006-df2b-4c53-b137-5d930a527247","id":"39e5d006-df2b-4c53-b137-5d930a527247","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Current & Previous Month","type":"Calendar Month","value":"0&-1","isCustomFilter":false,"customId":"115a294e-e0ed-405b-82fc-5ee4083bb7bc","id":"115a294e-e0ed-405b-82fc-5ee4083bb7bc","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Current & Next Month","type":"Calendar Month","value":"0&1","isCustomFilter":false,"customId":"36552d12-b977-433f-a5ed-5f052abe5d94","id":"36552d12-b977-433f-a5ed-5f052abe5d94","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Last Week","type":"Calendar Week","value":"-1","isCustomFilter":false,"customId":"1773cbcb-7b8b-4e08-a0dd-5f27cb0eb0d8","id":"1773cbcb-7b8b-4e08-a0dd-5f27cb0eb0d8","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"This Week","type":"Calendar Week","value":"0","isCustomFilter":false,"customId":"de89026f-f5f2-4914-98d8-5fbb626d5ec6","id":"de89026f-f5f2-4914-98d8-5fbb626d5ec6","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Next Week","type":"Calendar Week","value":"1","isCustomFilter":false,"customId":"edab4b2d-86c9-415b-8c9f-60cab8356ba6","id":"edab4b2d-86c9-415b-8c9f-60cab8356ba6","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Today","type":"Day","value":"0","isCustomFilter":false,"customId":"607596fd-1e09-4dba-a929-611b0e729522","id":"607596fd-1e09-4dba-a929-611b0e729522","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Yesterday","type":"Day","value":"-1","isCustomFilter":false,"customId":"110ac414-0c3b-4b16-879e-6249bbdc7751","id":"110ac414-0c3b-4b16-879e-6249bbdc7751","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Tomorrow","type":"Day","value":"1","isCustomFilter":false,"customId":"fe7e33d7-3b51-4727-b759-62f891153987","id":"fe7e33d7-3b51-4727-b759-62f891153987","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Last 7 Days","type":"Day","value":"-7","isCustomFilter":false,"customId":"fac2ee3e-0a31-4322-876c-642e4cbb17a6","id":"fac2ee3e-0a31-4322-876c-642e4cbb17a6","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Last 30 Days","type":"Day","value":"-30","isCustomFilter":false,"customId":"10c3733c-6743-4e94-b78a-651da8594689","id":"10c3733c-6743-4e94-b78a-651da8594689","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Last 60 Days","type":"Day","value":"-60","isCustomFilter":false,"customId":"655b7087-cf4d-4065-ad5b-65296e678db9","id":"655b7087-cf4d-4065-ad5b-65296e678db9","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Last 90 Days","type":"Day","value":"-90","isCustomFilter":false,"customId":"94290104-b096-48a1-90d2-657e0fd6fc22","id":"94290104-b096-48a1-90d2-657e0fd6fc22","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Last 120 Days","type":"Day","value":"-120","isCustomFilter":false,"customId":"cbf65ffb-5fd4-499c-8034-65c709af533c","id":"cbf65ffb-5fd4-499c-8034-65c709af533c","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Next 7 Days","type":"Day","value":"7","isCustomFilter":false,"customId":"20b7a28b-6a09-4bb1-9400-65c863f19c56","id":"20b7a28b-6a09-4bb1-9400-65c863f19c56","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Next 30 Days","type":"Day","value":"30","isCustomFilter":false,"customId":"013781da-925b-4cd7-a75b-67ef1f58252a","id":"013781da-925b-4cd7-a75b-67ef1f58252a","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Next 60 Days","type":"Day","value":"60","isCustomFilter":false,"customId":"bc00ee20-b7c6-47eb-8233-686e9813da32","id":"bc00ee20-b7c6-47eb-8233-686e9813da32","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Next 90 Days","type":"Day","value":"90","isCustomFilter":false,"customId":"2cb2bd5b-5228-470c-8ef7-68e8cc030f61","id":"2cb2bd5b-5228-470c-8ef7-68e8cc030f61","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Next 120 Days","type":"Day","value":"120","isCustomFilter":false,"customId":"5a0b0b87-e153-4047-97d7-6934bd0742e2","id":"5a0b0b87-e153-4047-97d7-6934bd0742e2","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"Next and Last 30 Days","type":"Day","value":"-30&30","isCustomFilter":false,"customId":"923fc0dd-6d08-483b-a9f9-6a2997698f1b","id":"923fc0dd-6d08-483b-a9f9-6a2997698f1b","state":0,"deleted":false,"inserted":true,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null}]

GET report/filter/dataFormat/{dataType}

Returns filter data formats for the specified data type.

Request

No payload

Response

An array of DataFormat objects

Samples

GET/api/report/filter/dataFormat/datetimeHTTP/1.1

Sample response:

[{"name":"MM/dd/yyyy","format":"MM/dd/yyyy","description":"01/01/2016","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"date","position":"1","id":"8074c8aa-55c7-4326-b6cd-0d4b0f7300cb","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"M/d/yyyy","format":"M/d/yyyy","description":"1/1/2016","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"date","position":"2","id":"99b3e614-e8b5-4029-92f4-0eb3b4567ee8","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"MM/dd/yy","format":"MM/dd/yy","description":"01/01/16","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"date","position":"3","id":"dac64bc3-f80d-471d-9c85-108e1b4ba12f","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"M/d/yy","format":"M/d/yy","description":"1/1/16","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"date","position":"4","id":"1a096ce2-ec61-434a-8661-111c1144d280","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"dd/MM/yyyy","format":"dd/MM/yyyy","description":"01/01/2016","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"date","position":"5","id":"39205d97-69c0-4218-aebc-1258050ee213","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"d/M/yyyy","format":"d/M/yyyy","description":"1/1/2016","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"date","position":"6","id":"37ea8e5a-221c-4e00-88c2-1462db60c321","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"dd/MM/yy","format":"dd/MM/yy","description":"01/01/16","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"date","position":"7","id":"47965d0b-abc8-4e20-a588-14c45a73c3f9","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"d/M/yy","format":"d/M/yy","description":"1/1/16","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"date","position":"8","id":"de0efa66-6346-4313-800c-1619704e1d77","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy/MM/dd","format":"yyyy/MM/dd","description":"2016/01/01","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"date","position":"9","id":"aae0b97a-0b8b-4279-b6ab-172b2a5a7b94","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy/M/d","format":"yyyy/M/d","description":"2016/1/1","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"date","position":"10","id":"dd8d2ffe-8df3-49b2-93e6-181b0a7d3823","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"MM-yy","format":"MM-yy","description":"01-16","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"yearandmonth","position":"11","id":"0833ea48-a1ec-43bc-889f-18c64165104f","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"M-yy","format":"M-yy","description":"1-16","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"yearandmonth","position":"12","id":"0549ff60-f999-4c9f-b7ce-19ca7136c108","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"MM-yyyy","format":"MM-yyyy","description":"01-2016","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"yearandmonth","position":"13","id":"8428b370-13c3-444e-aace-1a6310257460","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"M-yyyy","format":"M-yyyy","description":"1-2016","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"yearandmonth","position":"14","id":"0aec04a1-c573-4858-967d-1a65899905fb","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yy-MM","format":"yy-MM","description":"16-01","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"yearandmonth","position":"15","id":"1f15d83b-b08f-4fef-a2b8-1af83b3d3089","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yy-M","format":"yy-M","description":"16-1","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"yearandmonth","position":"16","id":"ce48ffc4-ba34-44b4-a6a3-1e3aa9bfb489","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy-MM","format":"yyyy-MM","description":"2016-01","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"yearandmonth","position":"17","id":"a5dc228e-87be-4131-89e7-21b2942ceb6c","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy-M","format":"yyyy-M","description":"2016-1","category":"Short Date","subCategory":"","dataType":"Date & Time","groupBy":"yearandmonth","position":"18","id":"5cde36e7-3bc1-46be-a0aa-22578b7b3dcf","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"[Month Name]-yy","format":"[Month Name]-yy","description":"January-16","category":"Long Date","subCategory":"","dataType":"Date & Time","groupBy":"yearandmonth","position":"19","id":"b330e42b-5f3f-449c-8437-24fcb3900cdc","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"[Month Name]-yyyy","format":"[Month Name]-yyyy","description":"January-2016","category":"Long Date","subCategory":"","dataType":"Date & Time","groupBy":"yearandmonth","position":"20","id":"d80cabee-2301-45e2-9923-252122708817","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy-[Month Name]","format":"yyyy-[Month Name]","description":"2016-January","category":"Long Date","subCategory":"","dataType":"Date & Time","groupBy":"yearandmonth","position":"21","id":"cd72509f-b5eb-4f6b-93c6-2631950aaad5","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yy-[Month Name]","format":"yy-[Month Name]","description":"16-January","category":"Long Date","subCategory":"","dataType":"Date & Time","groupBy":"yearandmonth","position":"22","id":"565be5b0-a2ec-44e9-a2dd-2b7e46b9ab89","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"[Day Names of the Week], [Month Name] dd, yyyy","format":"[Day Names of the Week], [Month Name] dd, yyyy","description":"Friday, January 01, 2016","category":"Long Date","subCategory":"","dataType":"Date & Time","groupBy":"date","position":"23","id":"518ebae0-be84-410e-8d61-2c121bd5c768","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"[Day Names of the Week], [Month Name] d, yyyy","format":"[Day Names of the Week], [Month Name] d, yyyy","description":"Friday, January 1, 2016","category":"Long Date","subCategory":"","dataType":"Date & Time","groupBy":"date","position":"24","id":"64742c1f-d2d0-46da-8e80-2c1cb57a55e1","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"HH:mm tt (12-hour time)","format":"HH:mm tt (12-hour time)","description":"01:05 AM","category":"Short Hour","subCategory":"","dataType":"Date & Time","groupBy":"time","position":"34","id":"69b175fb-a3f2-40bb-9162-2eb8cf5f7169","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"H:mm tt (12-hour time)","format":"H:mm tt (12-hour time)","description":"1:05 PM","category":"Short Hour","subCategory":"","dataType":"Date & Time","groupBy":"time","position":"35","id":"f629aeb7-7cd5-48e9-a194-30a1c9796b55","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"HH:mm (24-hour time)","format":"HH:mm (24-hour time)","description":"13:05","category":"Short Hour","subCategory":"","dataType":"Date & Time","groupBy":"time","position":"36","id":"2e2acfa1-02aa-42d6-872c-3188c2d423c9","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"H:mm (24-hour time)","format":"H:mm (24-hour time)","description":"1:05","category":"Short Hour","subCategory":"","dataType":"Date & Time","groupBy":"time","position":"37","id":"9ddf1adf-b54b-4b29-8fcf-32129371724d","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"HH:mm:ss tt","format":"HH:mm:ss tt","description":"01:05:20 AM","category":"Long Hour","subCategory":"","dataType":"Date & Time","groupBy":"time","position":"38","id":"55ae7c7a-f463-43ef-ba3a-327b02c5a196","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"H:mm:ss tt","format":"H:mm:ss tt","description":"1:05:08 PM","category":"Long Hour","subCategory":"","dataType":"Date & Time","groupBy":"time","position":"39","id":"f0692195-e1c7-4029-89b4-32bd89250f80","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"HH:mm:ss","format":"HH:mm:ss","description":"13:05:08","category":"Long Hour","subCategory":"","dataType":"Date & Time","groupBy":"time","position":"40","id":"c710dc48-20c8-4122-b213-3307cb096a01","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"H:mm:ss","format":"H:mm:ss","description":"1:05:08","category":"Long Hour","subCategory":"","dataType":"Date & Time","groupBy":"time","position":"41","id":"987f0bc1-1348-4b05-ad50-347a200c223f","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"MM/dd/yyyy HH:mm:ss tt","format":"MM/dd/yyyy HH:mm:ss tt","description":"01/01/2016 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"42","id":"9d33f3e0-b1ab-42fa-9b8e-356011065066","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"M/d/yyyy HH:mm:ss tt","format":"M/d/yyyy HH:mm:ss tt","description":"1/1/2016 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"43","id":"2a9e0025-7bc0-4cd7-bc73-364986805790","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"MM/dd/yy HH:mm:ss tt","format":"MM/dd/yy HH:mm:ss tt","description":"01/01/16 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"44","id":"8a3ab3b3-f3b3-4a92-a92d-38db2f8b1642","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"M/d/yy HH:mm:ss tt","format":"M/d/yy HH:mm:ss tt","description":"1/1/16 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"45","id":"617ab284-1175-4099-b0eb-3bb677630347","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"dd/MM/yyyy HH:mm:ss tt","format":"dd/MM/yyyy HH:mm:ss tt","description":"01/01/2016 01:05 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"46","id":"0d64d305-4a30-4e1e-8598-3bedce6a6922","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"d/M/yyyy HH:mm:ss tt","format":"d/M/yyyy HH:mm:ss tt","description":"1/1/2016 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"47","id":"936cc5c5-7f2a-4658-9623-3ca7ffc79774","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"dd/MM/yy HH:mm:ss tt","format":"dd/MM/yy HH:mm:ss tt","description":"01/01/16 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"48","id":"4c1e0945-dd57-4505-b52f-3cf82366966e","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"d/M/yy HH:mm:ss tt","format":"d/M/yy HH:mm:ss tt","description":"1/1/16 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"49","id":"ffff1be2-d4a3-4fe3-b1b3-3cfbbc19b602","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy/MM/dd HH:mm:ss tt","format":"yyyy/MM/dd HH:mm:ss tt","description":"2016/01/01 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"50","id":"0c6e93f8-8d3f-4606-b06f-3d97fce22f47","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy/M/d HH:mm:ss tt","format":"yyyy/M/d HH:mm:ss tt","description":"2016/1/1 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"51","id":"fa8c8ded-cb76-4c09-9e99-4005050c4c00","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"MM-yy HH:mm:ss tt","format":"MM-yy HH:mm:ss tt","description":"01-16 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"52","id":"f396a198-335a-4ff3-bc5f-40a45bff2b2c","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"M-yy HH:mm:ss tt","format":"M-yy HH:mm:ss tt","description":"1-16 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"53","id":"525f7687-51ae-4df9-8308-415e4713d1ee","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"MM-yyyy HH:mm:ss tt","format":"MM-yyyy HH:mm:ss tt","description":"01-2016 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"54","id":"49d4e3f7-6c74-4464-bca3-454d1b97de6f","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"M-yyyy HH:mm:ss tt","format":"M-yyyy HH:mm:ss tt","description":"1-2016 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"55","id":"90ace7c2-534c-4130-9a51-45f6d3fc1693","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yy-MM HH:mm:ss tt","format":"yy-MM HH:mm:ss tt","description":"16-01 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"56","id":"1bda7a16-2e0b-405c-b65f-465693fc47f6","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yy-M HH:mm:ss tt","format":"yy-M HH:mm:ss tt","description":"16-1 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"57","id":"27f16394-b625-43e0-a651-48069468f1be","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy-MM HH:mm:ss tt","format":"yyyy-MM HH:mm:ss tt","description":"2016-01 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"58","id":"4f2b4b1f-44ae-4e5d-9fdb-482b35bca7ca","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy-M HH:mm:ss tt","format":"yyyy-M HH:mm:ss tt","description":"2016-1 01:05:08 AM","category":"Short Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"59","id":"43a3ccd0-1f47-450c-9ff8-489099d3f44f","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"MM/dd/yyyy HH:mm:ss","format":"MM/dd/yyyy HH:mm:ss","description":"01/01/2016 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"60","id":"8079bc9c-199f-4f26-adb4-4b6a6e667a6e","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"M/d/yyyy HH:mm:ss","format":"M/d/yyyy HH:mm:ss","description":"1/1/2016 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"61","id":"3f1ec142-fd4b-4f6a-8f39-4d2901660360","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"MM/dd/yy HH:mm:ss","format":"MM/dd/yy HH:mm:ss","description":"01/01/16 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"62","id":"7844971b-6945-47d2-909c-4ee118d84b72","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"M/d/yy HH:mm:ss","format":"M/d/yy HH:mm:ss","description":"1/1/16 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"63","id":"5f12e0cf-b5b3-4fb8-966c-4ef10a75a211","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"dd/MM/yyyy HH:mm:ss","format":"dd/MM/yyyy HH:mm:ss","description":"01/01/2016 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"64","id":"e33e2fd3-3fa5-4a63-a700-522c62781d62","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"d/M/yyyy HH:mm:ss","format":"d/M/yyyy HH:mm:ss","description":"1/1/2016 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"65","id":"d91c8331-3a1e-4e1f-b1ec-558e465194b0","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"dd/MM/yy HH:mm:ss","format":"dd/MM/yy HH:mm:ss","description":"01/01/16 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"66","id":"57e7e874-f2e2-4a36-9213-56ba0500d62b","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"d/M/yy HH:mm:ss","format":"d/M/yy HH:mm:ss","description":"1/1/16 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"67","id":"eefd6063-e59d-42ec-a0d6-56cfb4daf691","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy/MM/dd HH:mm:ss","format":"yyyy/MM/dd HH:mm:ss","description":"2016/01/01 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"68","id":"784191b5-429d-4db3-9cd1-5764d2bd4f14","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy/M/d HH:mm:ss","format":"yyyy/M/d HH:mm:ss","description":"2016/1/1 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"69","id":"5ecab5c8-8ac7-4de7-a1b1-5a1647905941","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"MM-yy HH:mm:ss","format":"MM-yy HH:mm:ss","description":"01-16 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"70","id":"9934ed15-4eb2-4d24-9b5b-5a967abbb2b3","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"M-yy HH:mm:ss","format":"M-yy HH:mm:ss","description":"1-16 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"71","id":"e667285f-3b35-463f-9e74-5adb93569afe","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"MM-yyyy HH:mm:ss","format":"MM-yyyy HH:mm:ss","description":"01-2016 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"72","id":"4745208e-4ecc-4038-aac7-5afc7319c36b","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"M-yyyy HH:mm:ss","format":"M-yyyy HH:mm:ss","description":"1-2016 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"73","id":"e85030bc-8076-4e40-80b5-5b5f1196a292","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yy-MM HH:mm:ss","format":"yy-MM HH:mm:ss","description":"16-01 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"74","id":"3dfcc6e1-2391-4cc9-b263-5dac3359602a","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yy-M HH:mm:ss","format":"yy-M HH:mm:ss","description":"16-1 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"75","id":"ec708bba-7a50-4b1f-af5f-5dd8afc80110","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy-MM HH:mm:ss","format":"yyyy-MM HH:mm:ss","description":"2016-01 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"76","id":"353f1ebc-5d53-4802-a269-60516cd92ded","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy-M HH:mm:ss","format":"yyyy-M HH:mm:ss","description":"2016-1 13:05:08","category":"Short Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"77","id":"6d443fad-8764-497c-abe4-61c534e26787","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"[Month Name]-yy HH:mm:ss tt","format":"[Month Name]-yy HH:mm:ss tt","description":"January-16 01:05:08 AM","category":"Long Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"78","id":"4fa8464a-d29c-44e1-9ada-647b36b6d109","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"[Month Name]-yyyy HH:mm:ss tt","format":"[Month Name]-yyyy HH:mm:ss tt","description":"January-2016 01:05:08 AM","category":"Long Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"79","id":"ec36fff8-eccb-49a1-813c-67164e64d984","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy-[Month Name] HH:mm:ss tt","format":"yyyy-[Month Name] HH:mm:ss tt","description":"2016-January 01:05:08 AM","category":"Long Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"80","id":"cfe19542-05a0-4205-88c1-683a840bfab6","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yy-[Month Name] HH:mm:ss tt","format":"yy-[Month Name] HH:mm:ss tt","description":"16-January 01:05:08 AM","category":"Long Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"81","id":"196ca9d3-a366-45a9-9bd5-68b6fc3bddf2","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"[Day Names of the Week], [Month Name] dd, yyyy HH:mm:ss tt","format":"[Day Names of the Week], [Month Name] dd, yyyy HH:mm:ss tt","description":"Friday, January 01, 2016 01:05:08 AM","category":"Long Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"82","id":"0523248a-c64e-498e-b0b1-69eb20b817bb","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"[Day Names of the Week], [Month Name] d, yyyy HH:mm:ss tt","format":"[Day Names of the Week], [Month Name] d, yyyy HH:mm:ss tt","description":"Friday, January 1, 2016 01:05:08 AM","category":"Long Date & Long Hour","subCategory":"12-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"83","id":"73420f7b-ff6d-40c5-820e-6bb3e2953b41","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"[Month Name]-yy HH:mm:ss","format":"[Month Name]-yy HH:mm:ss","description":"January-16 13:05:08","category":"Long Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"84","id":"b8ac0da6-0300-4565-ba2a-6c1980eaa25b","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"[Month Name]-yyyy HH:mm:ss","format":"[Month Name]-yyyy HH:mm:ss","description":"January-2016 13:05:08","category":"Long Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"85","id":"9c544e73-32e9-4c7d-9de8-6c229bd73a3e","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yyyy-[Month Name] HH:mm:ss","format":"yyyy-[Month Name] HH:mm:ss","description":"2016-January 13:05:08","category":"Long Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"86","id":"7d463002-30df-4056-a14d-6c687e4e7a92","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"yy-[Month Name] HH:mm:ss","format":"yy-[Month Name] HH:mm:ss","description":"16-January 13:05:08","category":"Long Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"yearmonthandtime","position":"87","id":"c58457a6-98a1-4e69-92c9-6e093e2f58f3","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"[Day Names of the Week], [Month Name] dd, yyyy HH:mm:ss","format":"[Day Names of the Week], [Month Name] dd, yyyy HH:mm:ss","description":"Friday, January 01, 2016 13:05:08","category":"Long Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"88","id":"54c32a12-c057-42f6-b256-70d389788e88","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"[Day Names of the Week], [Month Name] d, yyyy HH:mm:ss","format":"[Day Names of the Week], [Month Name] d, yyyy HH:mm:ss","description":"Friday, January 1, 2016 13:05:08","category":"Long Date & Long Hour","subCategory":"24-hour","dataType":"Date & Time","groupBy":"dateandtime","position":"89","id":"3bd8ea56-6110-4057-9bd0-76086ec5ebcf","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null}]

GET/api/report/filter/dataFormat/numericHTTP/1.1

Sample response:

[{"name":"0.00","format":"0.00","description":"Positive: 15000.25, Negative: -15000.25","category":"Number","subCategory":"","dataType":"Numeric","groupBy":"","position":"90","id":"e31031c5-8be1-4266-abd9-773960317c56","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"0,000.00","format":"0,000.00","description":"Positive: 15,000.25, Negative: -15,000.25","category":"Number","subCategory":"","dataType":"Numeric","groupBy":"","position":"91","id":"42b78f79-bef7-4eb1-9e5d-77d7eb79411f","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"-(0.00)","format":"-(0.00)","description":"Positive: 15000.25, Negative: -(15000,25)","category":"Number","subCategory":"","dataType":"Numeric","groupBy":"","position":"92","id":"83575413-69d8-445c-a36a-78c8d654aba2","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"-(0,000.00)","format":"-(0,000.00)","description":"Positive: 15,000.25, Negative: -(15,000.25)","category":"Number","subCategory":"","dataType":"Numeric","groupBy":"","position":"93","id":"104a55b9-70fb-429c-a9d9-78d99cc09f53","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"$0.00","format":"$0.00","description":"Positive: $15000.25, Negative: -$15000.25","category":"Currency","subCategory":"","dataType":"Numeric","groupBy":"","position":"95","id":"a8813d10-9860-4564-99b1-7a562c523a8e","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"$0,000.00","format":"$0,000.00","description":"Positive: $15,000.25, Negative: -$15,000.25","category":"Currency","subCategory":"","dataType":"Numeric","groupBy":"","position":"96","id":"12506ff6-bef8-414d-a1c3-7b61ebbe6320","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"-($0.00)","format":"-($0.00)","description":"Positive: $15000.25, Negative: -($15000.25)","category":"Currency","subCategory":"","dataType":"Numeric","groupBy":"","position":"97","id":"bf844ffd-ee52-4bcb-b24c-7bb29b1cd4d1","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"-($0,000.00)","format":"-($0,000.00)","description":"Positive: $15,000.25, Negative: -($15,000.25)","category":"Currency","subCategory":"","dataType":"Numeric","groupBy":"","position":"98","id":"9022c8dd-ad27-47fa-b25c-7df7efee0559","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"0.00%","format":"0.00%","description":"Positive: 15000.25%, Negative: -15000.25%","category":"Percentage","subCategory":"","dataType":"Numeric","groupBy":"","position":"101","id":"c2ec0a9f-5c13-4db5-bf9a-80758c05ab0c","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"0,000.00%","format":"0,000.00%","description":"Positive: 15,000.25%, Negative: -15,000.25%","category":"Percentage","subCategory":"","dataType":"Numeric","groupBy":"","position":"102","id":"3b59cca3-159e-4814-8a11-8394c285ea6b","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"-(0.00%)","format":"-(0.00%)","description":"Positive: 15000.25%, Negative: -(15000.25%)","category":"Percentage","subCategory":"","dataType":"Numeric","groupBy":"","position":"103","id":"b5717e46-05ee-4304-8500-83d443c565ee","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null},{"name":"-(0,000.00%)","format":"-(0,000.00%)","description":"Positive: 15,000.25%, Negative: -(15,000.25%)","category":"Percentage","subCategory":"","dataType":"Numeric","groupBy":"","position":"104","id":"be821d25-8977-4473-b0d6-8457aa43175e","state":0,"version":null,"created":null,"createdBy":null,"modified":null,"modifiedBy":null}]
